Description
The T-256 is the first new product of SATIR’s thermal imagers & cameras of 2022. It has been developed in a response to end-users wanting a better image of the Entry Level cameras such as the D160 Pro. The T-256 is the perfect model in between entry and mid-level thermal imagers and a very affordable camera model. The T-256 has a 256×192 IR Detector which delivers 49,152 pixels to the end-user’s screen this is 29,952 pixels more than the D160 Pro. The T-256 has an Android Platform which makes it compatible with a range of Play Store Apps such as Gmail for emailing images. It has Wifi and bluetooth compatibility which allows easy transferring of images and video to other devices such as an tablet or phone. It has a good battery life of up to 5 hours which would be ideal for carrying out 2-3 building survey’s a day. It can be charged quickly and easily with a USB-C charging cable. It is suitable for Industrial applications such as mechanical, plumbing and electrical.
Key Features:
- 256×192 IR Detector
- Android Open Platform
- 30Hz Frame
- HDMI output for Images and Video
- Temperature Range –20°C ~ + 550°C
- Suitable for Industrial applications such as mechanical, plumbing and electrical
- Touch screen, easy to use new interface
T-256 Specifications:
Thermal Camera |
|
| Detector Type | UFPA |
| Detector Resolution | 256×192 |
| Pixel Size | 12µm |
| FOV/Min. Focus Distance | 56°x42° |
| Thermal Sensitivity (N.E.T.D) | ≤50mK (0.05°C)@30°C |
| Spectral range | 7.5~14um |
| IFOV | 3.4mrad |
| Focus Type/Min. Focus Distance | Fixed/50cm Focus Free |
Measurement |
|
| Temperature Range | -20°C ~ + 550°C |
| Accuracy | ±2°C or ± 2% of readings |
Image Presentation |
|
| Image Mode | IR/Digital/Fusion |
| LCD Display | 3”inch Capacitive Touch Screen (640×480 colour) |
| Frame Rate | 30Hz |
| File Format (Thermal/Digital) | JPEG |
| Image Storage | 64GB TF Card |
Power |
|
| Battery Type | 3.7 V 3500mAH Removable Li-ion Battery |
| Battery Life | 5 Hours |
Environment |
|
| Encapsulation | IP54 |
| Operating Temperatire | -20°C~+60°C |
| Shock | 25G |
| Vibration | 2G |
Physical Characteristics |
|
| Weight | <500g including battery |
| Dimensions | Height 25cm Camera Head Length 13cm |
Addtional Features |
|
| Operating System | Android |
| Ports | USB Type C, HDMI |
| Wi-Fi, Bluetooth, Light | Yes |
Accessories |
|
| Li-ion Battery, Power Supply, USB Cable & Carry Case |
Yes |
